Production Process

1.Twisting copper

01

Twisting copper

2.Extrudering1

02

Extruding

3.Twisting

03

Twisting

4.Spiralling Al-foil

04

Spiraling Al- foil

5.Papering Al-foil4

05

Papering Al- foil

6.Braiding

06

Braiding

7.Papering jacket3

07

Papering jacket

8.Cutting cable

08

Cutting cable

9.Injection-moulding magnetic ring

09

Injection- moulding magnetic ring

10.Cutting outside jacket1

10

Cutting outside jacket

11.Auto-cutting Al-foil1

11

Cutting Al- foil (auto)

12.Soldering2

12



Soldering / Auto- Soldering

13.First testing

13

Testing 1

14.Die-casting inner Molded

14

Die- casting inner Molded

15.Second testing1

15

Testing 2

16.Die- casting Outer Molded5

16

Die- casting Outer Molded

17.Product testing1

17

Testing 3

18.Spiraling cable1

18

Spiraling cable

19.Polybag packing

19

Polybag packing

20.Box packing2

20

Box packing
